Applicable Products
Applied to the medical industry, the product is compatible with square / circular ; a single product can be pasted with one film / two films / three films.
Product advantages
1.The self-developed visual alignment mounting software integrates the motion control system.
2. Operating system : Microsoft Win7 / Win8 / Win10, 64-bit or 32-bit.
3. The software interface is simple, easy to learn, easy to operate.
4. XYZ axis precision screw guide rail module, Feida feeder, replaceable nozzle group, belt rotary table type.
5. without tooling, fixture / assembly line transmission, general compatibility is not high.
6. Replace labor, save manpower, reduce management costs.
Technical indicators
1. Fitting accuracy : ± 0.05-0.1mm
2. The bonding efficiency : up to 2000PCS / H
3. Vision : non-standard customization ( can be customized according to the physical )
4. Membrane material specification : 150-300mm
5. Equipment specifications : non-standard customization
6. power supply requirements : 220 ± 10 % VAC, 50-60hz
7.Gas supply requirements : 0.4-0.7Mpa
